Rated Voltage | 12V | |
Voltage Range | 9~16V | |
Operating Temperature Range | -40~120℃ | |
Storage Temperature Range | -40~130℃ | |
Operating Angle | 320° | |
Rated Torque(Nm) | 1.0 | |
Stall Torque(Nm) | Max 1.5 | |
Operating Speed(RPM) | Min 4 | |
Rated Current(mA) | Max 400 | |
Stall Current(mA) | Max 1600 | |
IP CLASS | IP67 | |
LIN Ver | LIN 2.2A | Only for LIN Type |
Baud rate | 19200 | |
Function | Self-learning function | |
| * ??? ?? ??? ?? ?? | ||
